Iveco Marine CURSOR 8 Engine Turbocharger HX55WM 4045102 4045101 8043483

HX55WM
Model : HX55WM
Previous Version 4033329, 4033329H, 4045101
Part NO.: 4045102
CHRA 4032093 (1000020178)
Engine Cursor 8
KW 331/450 HP
Fuel Diesel
Turbine Wheel 4042782 (Ind. 85.85 mm, Exd. 71.95 mm, Trm 12.42, 12 Blades)(1100016395)
Comp. Wheel 3593629 (4040739, 4040740, 4041666)(Ind. 65.12 mm, Exd. 97.66 mm, Trm 6.09, 7+7 Blades, Superback)
Condition: brand new

Product Detail

Product Description

Part Number	4045102
Previous Version	4033329, 4033329H, 4045101
OE number	8043483, 5452052
Description	Marine
CHRA	4032093 (1000020178)
Turbo Model	HX55WM
Engine	Cursor 8
Engine Manufacturer	Iveco
KW	331/450 HP
Manufacturer Part Number	4033329
Fuel	Diesel
Angle α (compressor housing)	334°
Angle β (turbine housing)	290°
Bearing Housing	3590231 (4039258)(Oil Cooled)(1900011334)
Turbine Wheel	4042782 (Ind. 85.85 mm, Exd. 71.95 mm, Trm 12.42, 12 Blades)(1100016395)
Comp. Wheel	3593629 (4040739, 4040740, 4041666)(Ind. 65.12 mm, Exd. 97.66 mm, Trm 6.09, 7+7 Blades, Superback)(1200016217)
Back plate	3528096 (1153055300, 1800016024)
Heat shield Number	3529846 (3533038)(1153055340, 2030016003)
Repair Kit	3575181 (3580762)(1153055751, 5000020023)
Gasket Kit	215622 (2090505445)

Applications

2005- turbocharger for Iveco Marine with CURSOR 8 Engine
