Product Detail
Product Description
| Part Number | 743002-5002S |
| Previous Version | 743002-0002, 743002-2, 743002-0007 |
| OE number | 10R1927, 10R3199,170-025-0395, 262-7096, 2627096, 285-3253, 2853253 |
| Description | Earth Moving Compactor, Engines and Power Units, Wheel Dozer |
| CHRA Garrett | 710270-0072 (710270-5072S, 267-8584, 2678584) |
| Turbo Model | GTA4702BL, GTA4702BLS |
| Earth Moving Compactor | 826C, 825C |
| Machine Engine | C15 |
| Wheel -Type Loader | 980H |
| Wheel Dozer | 824C |
| S/N | LHX1-UP, LHX15363-UP, CLAM 28253, NLK00001-UP, RCY00001-UP, ZLK00001-UP, DXR00001-UP, JLK00001-UP, JMS00001-UP, MHG00001-UP, 85X00001-UP, 2KR00001-UP, RCM00001-UP, TXG1-UP |
| Fuel | Diesel |
| Prefix | 85X, 86X, 87X, 2KR, 2SR, A8J, JMS, KZL, MHG, MKP, P8B, 99Z, MGC |
| Engine | 824C, 825C, 826C, 980G, 980H |
| Angle α (compressor housing) | 15º |
| Angle β (turbine housing) | 65º |
| Bearing Housing | 708605-0001 (Oil Cooled) |
| Turbine Wheel | 702892-0001 (Ind. 83.87 mm, Exd. 92.8 mm, 10 Blades, Boreless) |
| Comp. Wheel | 726400-0003 (Ind. 76.45 mm, Exd. 102.26 mm, 6+6 Blades, Boreless, Superback) |
| Back plate | 706668-0018 (408487-0003) |
| Heat shield Number | 407778-0001 NEW IN STOCK |
| Repair Kit | 709153-0001 (468267-0010) |
| Turbine Housing | 740976-0002 (302-7435, 10R-8968) |
| Turbine Housing & W/G | 740979-0006 |
| Compressor Cover | 447992-0086 (70569-0094) |
| Turbine Housing A/R | 1.59 |
| Actuator | 452603-0051 (452603-0045) |
| Gasket ( turbine inlet) | 409038-0000 (409038-0001, 210835-0000, 9749, 210017-0000)(7M7273, 305726, 1900000003, 3316409038, 1S4295, 8A0943) |
| Gasket oil inlet | 210161 (Paper) |
| Gasket ( oil outlet | 210172 (Paper) |
| Gasket water | 210021 (409037-0000, 210021-0000, 311496, 413671-0000)(Paper) |
| Gasket Kit | 215124 |
| NOTE | Intercooler, Magnetic Shaft Nut |
Applications
turbocharger for Caterpillar Earth Moving with 980H, C15 Engine
