Product Detail
Product Details
| Part Number | 3773926 |
| Previous Version | 404420, 4044201-D, 4031195, 4044200, 4044200-D, 4044201, 4043163, 4043161, 4038876, 5324768, 5324766 |
| OE number | 20857657 5324768 3773927 |
| Description | Truck FH-FM 13 |
| CHRA | 4031406 (403140600) (1000020172T) |
| Turbo Model | HX55-D98K68RAV/A86J93PAC25WX , HE500FG, HX55 |
| Engine | MD13 (EURO 3) EC480 D13 EC380 D13D D13F D13 SDLG |
| Manufacturer | BOOSHIWHEEL |
| KW | 480/520 HP |
| Displacement | 13.0L, 13000 ccm |
| Fuel | Diesel |
| Angle α (compressor housing) | 125° |
| Angle β (turbine housing) | 180° |
| Bearing Housing | 3590231 (4039258)(1153055451)(1900011334) |
| Turbine Wheel | 3533543 (4038182)(Ind. 86. mm, Exd. 80. mm, 12 Blades)(1153055435, 1100016168) |
| Comp. Wheel | 4035468 (Ind. 67. mm, Exd. 99. mm, 6+6 Blades)(1153052400, 1200016360T)(MFS) |
| Back plate | 3528096 (1153055300, 1800016024) |
| Heat shield Number | 3529846 (3533038)(1153055340, 2030016003) |
| Repair Kit | 3580762 (3575181)(1153055750, 5000020025B) |
| Gasket (turbine inlet) | 409123-0002 (310694)(Inox Steel) |
| Gasket (oil outlet) | 210060 (311585, 148062, 409267-0003, 409267-0002, 210060-0000, 51914)(Paper) |
Application
2005-10 Turbocharger for Volvo FH-FM 13 Truck MD13 (EURO 3) Engine
