Product Detail
Product Description
| Part Number | 4043620 |
| Previous version | 3590901, 3590902, 3592158, 3592518, 3592544, 3592548, 3593613, 3593614, 3594595, 3594763, 3596617, 3596624, 3596625, 3800652, 3800652NX, 3800652RX, 3800770, 3800770NX, 3800770RX, 3800997, 3800997NX, 3800997RX |
| OE number | 4025320, 4025320NX, 4025320RX, 4089760, 4090043, 5324942, 4089760, 4089760NX, 4089760RX, 4090043, 4090043NX, 4090043RX |
| Description | Truck, Industrial Various Kenworth, Peterbilt, Komatsu Industrial Gen Set |
| Manufacturer Part Number | 3596624, 3596625, 4038282, 4038283, 4040850, 4040851, 4043621, 4043622, 53227754H, 5323079, 5327752, 5327753, 532775300, 532775300H, 532775300HX, 5327753H, 5327753HX, 5327754, 532775400, 532775400HX, 5327754H, 5327754HX |
| CHRA | 4027674 (4027674H) $1180.00 NEW IN STOCK |
| Turbo Model | HE600WG, HX60W |
| Engine | ISX2 Non-EGR Engine, Signature ISX3 |
| Displacement | 15.0L, 1500 ccm |
| KW | 600 HP |
| Fuel | Diesel |
| Angle α (compressor housing) | 180/270° |
| Angle β (turbine housing) | 136/160° |
| Bearing Housing | 4027673 (Oil Cooled) $226.90 NEW IN STOCK |
| Turbine Wheel | 3539388 (Ind. 85.11 mm, Exd. 97.3 mm, 11 Blades) $675.90 NEW IN STOCK |
| Comp. Wheel | 4036701 (Ind. 73.45 mm, Exd. 107.32 mm, 8+8 Blades, Superback) $490.94 NEW IN STOCK |
| Back plate | 3531917 (1250403300) $67.06 NEW IN STOCK |
| Heat shield Number | 3519155 (18373)(351915500) $15.58 NEW IN STOCK |
| Repair Kit | 3580568 (3545345, 4027880)(1153060750) $125.00 NEW IN STOCK |
| Gasket Kit | 4032516 |
| Superseded | 5327752 |
Application
2006-08 turbocharger for Cummins Various with ISX2 Engine
2000-08 turbocharger forKomatsu Industrial Gen Set S500 with ISX2 Engine
