Product Detail
Product Description
| Part Number | 53269886750 |
| Previous Version | 5326-988-6750, 5326 988 6750, 53269886752, 5326-988-6750 |
| OE number | 2179089, 2179080, 3581012, 3802112, 3802105 |
| Year | 1995-10 |
| Description | Ship |
| Manufacturer Part Number | 53269706752, 53269706750, 5326-970-6752, 5326-970-6750 |
| CHRA | 53267100080 (5326-710-0080) |
| Turbo Model | K26-3267OGAAA10.71GAAXB |
| Engine | KAD43, KAMD43, KAD44, KAMD44, M16, KAD44P |
| Displacement | 3.59L, 3590 ccm |
| KW | 190/258/260 HP |
| RPM Max | 3800/4300 |
| Fuel | Diesel |
| Angle α (compressor housing) | 43° |
| Angle β (turbine housing) | 315° |
| Bearing Housing | 53241500004 (53261500026, 53261500016)(858705)(Oil Cooled) $150.34 NEW IN STOCK |
| Turbine Wheel | 53261205001 (Ind. 64.3 mm, Exd. 54.5 mm, Trm 10.1, 12 Blades)(1301026436) |
| Comp. Wheel | 53271232323 (Ind. 55.7 mm, Exd. 82.6 mm, Trm 9.2, 7+7 Blades, Billet) |
| Back plate | 53271515739 (53271515738) |
| Heat shield Number | 53261652005 (858668)(53261652007) |
| Repair Kit | 53267110039 (53267110001, 53277110053)(1301026752, 5000040117B) |
| Turbine housing (water-cooled) | 53261006426 (53261006427) |
| Compressor Cover | 53271014939 (53271015103) |
| Turbine Housing AR | 12 |
| Gasket (turbine inlet) | 210294 (Inox Steel) |
| Gasket oil inlet | 210023 (420641) |
| Gasket (oil outlet) | 210060 (860105) |
| NOTE | Inter-cooler |
Applications
2002-10 turbpcharger for Steyr Marine with M16/KAD/KAMD Engine
1995-06 turbpcharger for Volvo-Penta Ship with M16/KAD/KAMD Engine
