Yanmar Marine 6LY2A ENGINE TURBO 119575-18020 RHC7W MYDS C72CAD-S0055B

119575-18020 RHC7W
Model : RHBC7W RHC7W-12307P22NWBRB6235SUCZ
Part Number VA290055 VB290055, VC290055, VD290055
V-SPEC. MYDS
OE number 119575-18020 1-19575-18020 1-19575-1802-0, 11957518020, C72CAD-S0055B, C72CADS0055B
CHRA (C72CAD-S0055C, C72CADS0055C)
Engine 6LY2A-STP, 6LY2ASTP
Displacement 58.13L, 5813 ccm
Power 440 HP
Fuel Diesel
Repair Kit NH179874 (509T-526)

Product Detail

Product details

Part Number	VA290055
Previous Part Number	VB290055, VC290055, VD290055
V-SPEC.	MYDS
OE number	119575-18020, 1-19575-18020, 1-19575-1802-0, 11957518020, C72CAD-S0055B, C72CADS0055B
Description	Marine
CHRA	(C72CAD-S0055C, C72CADS0055C)
Turbo Model	RHC7W-12307P22NWBRB6235SUCZ
Engine	6LY2A-STP, 6LY2ASTP
Displacement	58.13L, 5813 ccm
Power	440 HP
Fuel	Diesel
Angle α (compressor housing)	65°
Angle β (turbine housing)	90°
Bearing Housing	NE973420 (Oil Cooled)
Turbine Wheel	NH172002 (Ind. 66.27 mm, Exd. 73. mm, 12 Blades)
Comp. Wheel	NH175702 (Ind. 60.6 mm, Exd. 81.98 mm, Trm 4.88, 6+6 Blades, Superback) $275.90 NEW IN STOCK
Back plate	NN172500 $188.50 NEW IN STOCK
Repair Kit	NH179874 (509T-526)
Turbine Housing (Water Cooled)	NE977160
Compressor Cover	NE974250
Turbine Housing AR	22
Installation Kit	$79.00
Gasket (turbine Outlet)	128300-13230
Gasket (oil outlet)	210161 (128300-1323)(Gasket paper)

Applications

TURBOCHARGER FOR Yanmar Marine with 6LY2A-STP Engine
