Hino Marine RHC61W Turbo VC240036 24100-1350A MX58 MX33 24100-1820A 6T-546 831001350

MX58 MX33 24100-1820A
Model : RHC61W RHC61W-943P27NWBRLL489CB
Part Number VC240036 VA240036, VB240036, VC240036
OEM: 6T-546, 831001350, 24100-1350A, 241001350B, 24100-1350B. 241001350A, 831001621
OE numbers: 24100-1820A, 24100-1820B, 24100-1821A, 24100-1821B, 241001820A, 241001820B, 241001821A, 241001821B, 6T-573, 6T573
V-Spec MX58
ENGINE Model : WO4CTI W 04 C -CT, W04CT-I, WO4CTA
KW 150/234 HP
Displacement I/L4 Cylinders
Fuel Diesel
Applications 1990- Hino Marine With WO4CTI, W04C-CT Engine 1990- Mercury, Mercruiser With Marine W04C-CT Engine

Product Detail

Product Description

Part Number	VC240036
Previous versions	VA240036, VB240036, VC240036
OE number	6T-546, 831001350, 24100-1350A, 241001350B, 24100-1350B. 241001350A, 831001621
V-Spec	MX58
Description	Marine Mercuiser, Mercury Marine MIE
Model	W 04 C -CT, W04CT-I, WO4CTA
CHRA	NZ852970 (831501140)
Turbo Model	RHC61W-943P27NWBRLL489CB
Model	33912C9FS, 33922B9DD
Engine	WO4CTI
KW	150/234 HP
Displacement	I/L4 Cylinders
Fuel	Diesel
Angle α (compressor housing)	245°
Angle β (turbine housing)	355°
Bearing Housing (Water Cooled)	NH163331 (831211260)(831211090)
Turbine Wheel	NH261201 (834999998, 241001350)(834999998)
Comp. Wheel	NH265507 (831181200, 831181100, 241181200)
Back plate	831271160 (241271160, 831271090)
Heat Shield	831411140 (241411140, 831411090)
Nozzle	831321110
Repair Kit	KT-RHC6X
Turbine Housing	NH167542 (831111440, 831211090, 241111440)
Compressor Cover	NH264422 (831141130, 241411140)
Turbine Housing AR	27
Gasket (turbine inlet)	241791170
Gasket (oil outlet)	831351080 (831351080, 241351081) $8.20
Plug	962610050
Plug	962613060
Insulator Cover	831441030
