Hino Earth Moving WO4CTA Marine engine turbo MX33 RHC6W 24100-1820A

MX33 RHC61W 24100-1820A
Model : RHC61W RHC61W-1182P20NWBRL504A
Part Number VB240021 NH160019, NH160023, VA240021, VC240021, VD240021
Previous versions 6T-573, 6T573, C61CND-S0021B, C61CND-S0021G, C61CNDS0021B, C61CNDS0021G, S1760-E0770, S1760E0770
OE number 24100-1820A, 24100-1820B, 24100-1821A, 24100-1821B, 241001820A, 241001820B, 241001821A, 241001821B
V-Spec. MX33
CHRA NZ853753
Engine W04CTA, W04CT-I
Repair Kit NH169843
condition: brand new
Applications Hino Earth Moving WO4CTA (150 H.P.) 4 CYL.

Product Detail

Product Description

Part Number	VB240021
Previous versions	NH160019, NH160023, VA240021, VC240021, VD240021
OE number	24100-1820A, 24100-1820B, 24100-1821A, 24100-1821B, 241001820A, 241001820B, 241001821A, 241001821B, 6T-573, 6T573, C61CND-S0021B, C61CND-S0021G, C61CNDS0021B, C61CNDS0021G, S1760-E0770, S1760E0770
V-Spec.	MX33
Description	Earth Moving
CHRA	NZ853753
Turbo Model	RHC61W-1182P20NWBRL504A
Engine	W04CTA, W04CT-I
KW	150 HP
Fuel	Diesel
Angle α (compressor housing)	245°
Angle β (turbine housing)	355°
Bearing Housing	NH163303 (S241211130)(Oil Cooled)
Turbine Wheel	NH161402 (BR504A)(Ind. 56.33 mm, Exd. 61.08 mm, 11 Blades)(S241151120, S241501140)
Comp. Wheel	NH165203 (NH161300)(Ind. 44.32 mm, Exd. 64.95 mm, 5+5 Blades, Superback)(S241181100)
Back plate	NN193012 (S241271090) $61.40 NEW IN STOCK
Heat shield Number	NH261107 (S241411100)
Repair Kit	NH169843
Turbine Housing (Water Cooled)	NH167524
Compressor Cover	NH164605
Gasket (turbine inlet)	210235 (Stainless Steel)
Gasket (oil outlet)	210161 (128300-1323, Gasket paper)

Applications

turbocharger for Hino Earth Moving WO4CTA (150 H.P.) 4 CYL.
