Product Detail
| Part Number | 319034 |
|---|---|
| Previous Version | 12679880000, 1267-988-0000, 1267 988 0000 |
| OE number | 35242100, 35242100F, 35242183F |
| Year | 2002- |
| Description | FITS FOR VM Motor Mercruiser/Marine, Ship |
| Manufacturer Part Number | 318789, 12679700000, 1267-970-0000 |
| CHRA | 319035 |
| Turbo Model | S200W |
| Engine | MD706L |
| Displacement | 4.16L, 4160 ccm |
| KW | 223/300 HP |
| RPM Max | 2400 |
| Fuel | Diesel |
| Angle α (compressor housing) | 245° |
| Angle β (turbine housing) | 315° |
| Bearing Housing | 317242 (Oil Cooled) |
| Turbine Wheel | 318925 (Ind. 57.6 mm, Exd. 66. mm, 11 Blades) NEW IN STOCK |
| Comp. Wheel | 169937 (Ind. 51.11 mm, Exd. 80. mm, 7+7 Blades, Superback) |
| Back plate | 167997 (306010011) |
| Repair Kit | 318382 (315565, 318383)(1253200750) |
| Turbine Housing (water-cooled) | 318924 |
| Compressor Cover | 318922 |
| Gasket (turbine inlet) | 312617 (409039-0001, 210190-0000, 132044) |
| Gasket (oil outlet) | 311496 (409037-0000, 210021-0000, 413671-0000, 3519807, 210021)(1900000027) |
| Gasket (oil inlet) | 147837 (409036-0000, 409026-0001, 409266-0001, 210023-0000, 3755739, 3709737, 3500681, 3519762, 55739, 210023)(1900000037) |
