Product Detail
Product details
| Part Number | 466082-5002S |
| Previous Version | 466082-0001, 466082-0002, 466082-5001S, 466082-1, 466082-2 |
| OE Number | 08923640, 8923640, R8923640, 08925686, 8925686 |
| Year | 2003-08 |
| Description | Marine |
| CHRA | 441663-0001 (441663-5001S)(8927056) |
| Turbo Model | TW4103, TW4105 |
| Fuel | Diesel |
| Displacement | 8.2L, 8200 ccm |
| KW | 300 HP |
| NSN | 2950-01-247-1845, 2950012471845 |
| Angle α (compressor housing) | 161º |
| Angle β (turbine housing) | 340º |
| Bearing Housing | 407285-0046 (8927057)(Oil Cooled) |
| Turbine Wheel | 410982-0001 (8927060) |
| Comp. Wheel | 409535-0001 (8927062)(Ind. 58. mm, Exd. 76. mm, Trm 58, 7+7 Blades, Billet) |
| Back plate | 408045-0009 (446560-0001)(8927061) |
| Heat shield Number | 441378-0000 (8927059) |
| Repair Kit | 468100-0000 (188401-0000, 3524796, 2W0716, 6N7236, 310063, 79025721)(1100040750, 5000010041) |
| Turbine Housing (Water Cooled) | 441279-0004 (8927065) |
| Compressor Cover | 409722-0002 (8927064) |
| Turbine Housing AR | 1.30 |
| Gasket (turbine inlet) | 210362 (Metal & paper) |
| Gasket oil inlet | 210023 (210023-0000, 147837, 215234, 55739, 3709737, 3500681, 3519762, 409266-0001, 409036-0000, 409026-0001, 52231586500)(1900000037)(Paper) |
| Gasket(oil outlet) | 210021 (210021-0000, 409037-0000, 413671-0000, 3519807, 311496)(1900000027) (Paper) |
| Manufacturer |
