Product Detail
| Part Number | 721853-5003S |
| Previous Version | 721853-0003, 7218530003, 721853-3 |
| OE number | 305866A, 305865A |
| CHRA | 449530-0041 (449530-5041S) |
| Turbo Model | UTV8133 |
| Fuel | CNG |
| Angle α (compressor housing) | 238º |
| Angle β (turbine housing) | 15º |
| Bearing Housing | 449072-0016 (Oil Cooled) |
| Turbine Wheel | 449587-0001 (Ind. 97.10 mm, Exd. 111.45 mm, Trm 16.59, 11 Blades) |
| Comp. Wheel | 449587-0001 (443121-0003)(6I0849)(Ind. 80.6 mm, Exd. 117.6 mm, Trm 8, 7+7 Blades) |
| Back plate | 442732-0005 |
| Heat Plate | 407657-0009 |
| Repair Kit | 468267-0010 (1101085750) |
| Turbine Housing | 408499-0044 (1W6553) |
| Compressor Cover | 446824-0002 |
| Turbine Housing AR | 1.23 |
| Gasket (turbine inlet) | 409038-0001 |
| Gasket oil inlet | 129119 (1900000035)(201049, 9737, 1S6595, 210019-0000, 409266-0003, 3819900) |
| Gasket (oil outlet) | 210018 (129120, 210018-0000, 409267-0002, 3709738, 3500682, 201048, 1S4810, 9988, 9738, 3519763) (1900000025) |
| Replaced By | 721853-0001 |
