Alaska Diesel, Volvo Penta Ship K27 Turbo 53279707090 843663 3802012 53279887090

Product Detail

Turbo Details

Part Number	53279887090
Previous Version	5327-988-7090, 5327 988 7090, 5327-988-7090
OE number	30-31627-1, 843663, 3802012
Year	1977-07
Description	fits for Ship, Marine, Alaska Diesel, Komatsu
Manufacturer Part Number	53279707090, 5327-970-7090, 5327 970 7090
CHRA	53277100000 (5327-710-0000)(NL# 30-00027)
Northern Lights (Lugger)	30-31627-1
Turbo Model	K27-2970N14.71GZATB
Engine	used for John-Deere 6-359, TAMD60, TAMD60B
Displacement	5.9L, 5900 ccm
KW	100/134/197/200
RPM Max	1800/2500
Fuel	Diesel
Angle α (compressor housing)	90°
Angle β (turbine housing)	90°
Bearing Housing	53271500010 (NL# 30-31633)(53271500001, 53271500004, 53271500006)(Oil Cooled)(1301027450)
Turbine Wheel	53271202103 (NL# 30-31637)(53271205013, 53271202105)(Ind. 60.25 mm, Exd. 75.56 mm, Trm 11.6, 12 Blades)(1301027435)
Comp. Wheel	53271232236 (NL# 30-31646)(53271232002)(Ind. 55.83 mm, Exd. 49.17 mm, Trm 2970N, 6+6 Blades, Flatback)(1301027406)
Back plate	53271515708 (NL# 30-31643)
Heat shield Number	53271652003 (NL# 30-31659)(53271652002)
Repair Kit	53277110001 (NL# 30-31630)(1301027753, 5000040117B)
Turbine Housing (water-cooled)	53271006408 (53271006400, 3271006404)(NL# 30-31628)
Compressor Cover	53271015004 (NL# 30-31629)
Turbine Housing AR	14
Gasket turbine inlet (single flow)	52231083000 (NL# 11-31615)
Gasket (oil outlet)	52231586501 (210060, 210023-0000, 147837, 210021, 215234, 55739, 3709737, 3500681, 3519762, 409266-0001, 409036-0000, 409026-0001)(1900000037)
Gasket (oil inlet)	52231586500
NOTE	NL# Northern Lights

Applications

1977-07 TURBOCHARGER FOR Alaska Diesel Ship with John-Deere 6-359, TAMD60 Engine

1977-07 TURBOCHARGER FOR Volvo Penta, Komatsu Ship with John-Deere 6-359, TAMD60 Engine
